80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands

80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands
80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands 80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands 80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands

Large Image :  80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands

Product Details:
Place of Origin: China
Brand Name: Guoheng
Certification: CE, ISO9000
Model Number: GZD series
OEM: Acceptable
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Mainframe naked in container and electric control part packed in plywood case then in container;
Delivery Time: 25days
Payment Terms: TT/LC
Supply Ability: 20sets/month
Price terms: FOB (Shanghai) or CIF (named port)
Detailed Product Description
High Light:

pipe rollers for welding

,

pipe welding rotators

80T Electric Bolt Welding Rotator Pipe Roller Stands Adjustable





1. Quick Detail



  • Bolt adjustable pipe welding rotator with travel boogie;
  • Broadly used in pipe or vessel fit-up processes;
  • Schneider or Panasonic inverter to realize VFD speed control and synchronous rotation of rollers;



2. Main Parameters



Model

HGK80Y

Max loading T

80

Suit diameter mm

Min

2000

Max

4500

PU Roller mm

Dia

500

Width

400

Linear speed m/h

6--60

Speed Control

VFD

Boogie travel speed mm/min

300-3000

Inner rail span mm

2000

Roller motor power kW

2*2.2

Boogie motor power kW

2*1.1

Above are our standard models and parameters, and it can be designed and manufactured on request.


   *We reserve the right to alter specifications without prior notice.



3. Main features



The standard models of our pipe welding rotator or roller beds have the following features:

  • Steplessly controllable rotary drives by means of A.C. or D.C. motor (on request) drive via self-locking
  • worm gear reducers;
  • Schneider or Panasonic inverter to realize VFD speed control and synchronous rotation of rollers;
  • Heat treatment to main welding parts after welding; sand blasting treatment to main welding parts before
  • painting;
  • Fine machining to upper surface of base;
  • Roller distance is bolt adjustable and roller surrounding angle among 45°~110°;
  • All motion parts have lubrication system;
  • Main electric elements are ABB/Siemens brands;
  • Hand pendant with Forward-Stop-Reverse and speed potentiometer are standard;
  • Lifting lug on the base of roller bed;
  • Standard color:


Optional features:


  • Roller material options: Metallic or Rubber roller;
  • Self-centering/self-alignment rack;
  • Foot switch;
  • Servo drive;
  • Anti-explosion motor&control panel;



4. Supply range



  • Driving turning roll                                               1set
  • Idle turning roll                                                  1set
  • Electric control system [including 1piece of electric control cabinet, 1piece of remote control  box with cable 6m]                                 1set
  • Technical documents (with manual book, conformity certificate, packing list, etc)                                                                        1set

5. Reference photo



80T electric Bolt Adjustable Welding Rotator with travel Boogie , pipe roller stands 0





6. Comparative advantage



  • ISO9000&CE certified;
  • Professional and experienced engineer team to ensure the advanced design about structure and electric;
  • Experienced and skilled workers to care for each work flow from material cutting, welding, grinding to final assembly and testing to ensure high machine quality;
  • Professional and experienced after sale service team to guarantee quick and satisfied installation, commissioning or service;
  • Optimum materials and outsourcings to ensure the best performance;
  • Commissioning and testing before delivery;
  • Factory inspection is encouraged;
