Bolt Screw Adjustable Conventional Welding Rotator , AC Frequency Converter

Large Image : Bolt Screw Adjustable Conventional Welding Rotator , AC Frequency Converter

Product Details:

Place of Origin:	China
Brand Name:	Friendship Machinery
Certification:	CE, ISO
Model Number:	CWR Series

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	Standard package
Delivery Time:	30 working days after down payment

Contact Now

Detailed Product Description

High Light:

Welding Turning Rolls

Weld Rotator

Bolt Screw Adjustable Conventional Welding Rotator , AC Frequency Converter

1. Machine introduction

The CWR type conventional welding rotators have advantages of the same kinds of products in domestic and international. We design and make them according to the requirments of the pressure vessel factory. These products are applied in the handling and automatic welding of the metal circle containers, they have many advantages such as advanced technology, easy operation.
The rotators have two kinds, adjustable and conventional, it can used in all kind of the diameter and frequency conversion setting, low sound, work placidity.

2. Technical parameters

Type			CWR5	CWR10	CWR20	CWR30	CWR40	CWR50	CWR60	CWR80	CWR100
Load			5	10	20	30	40	50	60	80	100
Rollerl	Metal roller	Diameter (mm)	240	290	340	340	390	390	440	490	490
	Metal roller	Width (mm)	20	25	30	30	40	40	50	60	80
	Rubber roller	Diameter (mm)	250	300	350	350	400	400	450	500	500
	Rubber roller	Width (mm)	100	120	120	120	120	120	120	120	120
Tube body diameter	Minimum (mm)		250	320	500	530	600	750	750	850	1000
Tube body diameter	Maximum (mm)		2300	2800	3500	3700	4200	4500	4800	5000	5000
Wheel velocity (m/h)			6-60	6-60	6-60	6-60	6-60	6-60	6-60	6-60	6-60
Power of motor (KW)			0.75	1.1	1.5	2.2	3	4	4	4	5.5
Way of setting			Electric magnetism of frequency conversion setting

welding rotator is used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber. It can be aligned according to the size of the shell, it is controlled with AC frequency converter, and the linear velocity is displayed by the digital.

We also can design the customize various types of the welding rotator in accordance with the customers requirement.
