Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel

Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel
Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel

Large Image :  Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel

Product Details:
Place of Origin: CHINA
Brand Name: Friendship Machinery
Certification: CE, ISO
Model Number: FSM-CWR Series
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Steel framework and wire mesh
Supply Ability: 30 sets per month
Detailed Product Description
High Light:

Welding Turning Rolls

,

Weld Rotator

Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel







1. Technical parameter


● Model: FSM-CWR-10
● Load capacity: 10T (1 power & 1 idler rotator)
● Rotation speed: 102-1020mm/min
● Vessel diameter: 236-5418mm
● Incoming supply: 380/415V, 3 Phase, 50-60HZ (specify input voltage when ordering)
● AC Inverter: 1.1KW
● Motor rating: 2 * 0.55KW AC motors
● Control voltage: 24V low voltage control
● Weight: 520Kg power rotator and 240Kg idler rotator





2. Main features


● Push button pendent control with maintained for, stop, rev and speed adjustment.
● Infinitely variable wheel center distance by hand wheel through lead screw allows for fast

center distance adjustment and optimum contact angle.
● Heavy duty worm gear drives on each drive roll eliminates the many problems associated

with drive shaft systems.
● Each drive system is oil immersed for long life and sealed from contaminants such as weld

spatter and slag.
● Fully machined top bed on idler and drive roll for perfect alignment.
● AC inverter drive with LED frequency display for speed adjustment.
● Highest quality design and construction available for years of trouble free service.



Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel 0



Conventional Weld Rotator Welding Column Boom 236 - 5418mm Vessel 1
