IGBT inverter control type pipe-tube sheet automatic pulse argon pipe welding
Applicable industries and scope
KHBT Series cylinder body wall saddle type full-automatic pulse tube plate argon arc welding machine can be used in boiler, heat exchangers, pressure containers of small tube and bassoon and body orthogonal carbon steel, stainless steel tube plate of all position of welding.
KHBT51 welding machine is mainly used for pipe diameter for 51mm and inner diameter for 800mm-2400mm cylinder body wall saddle type tube plate welding.
Special size of pipe and tube body as well as the special assembly way, can customize according to the requirements of customers.
Function and Features
1. Compact design, welding head equipped with special mobile vehicles, easy operation. Under the car equipped with electromagnet structure to ensure welding torch when soldering positioning reliable and accurate. Electromagnet disconnect, dolly can move freely in the cylinder.
2, Welding torch rotation system, wire feeding system and mention arc system triaxial integration, PLC control, make saddle type weld moulding evenly, beautiful.
3,Welding torch using forced circulation water cooling, continuously work long hours.
4,The positioning spindle using water-cooled manner to avoid overheating pipe head loss.
5,System adopts PLC control and it is stabilization and reliable, strong anti-jamming.
6, The man-machine interface adopts LCD touch screen, English input, the operation is simple, intuitive convenient.
7,Adopt Panasonic IGBT inverter control dc pulsed Tig welding power, high efficiency, arc stability strong, weld bead moulding beauty.
8,The machine adopts compulsory air-cooled water cooling circulatory system, equipped with 16 liters stainless steel tank, not affected by field water hydraulic conditions of limits, cooling fully, reliable convenient.
Technical parameters
Weldable diameter | 51mm |
Weldable tank diameter | 800\1000\1200\1400\1600\1800\2200\2400 (mm) |
Welding torch can tilt Angle | 25-35DEG |
Welding torch turning speed | 0-9rpm |
Wire feeding speed | 0-2500mm/min |
Power control mode | IGBT inverter control |
Rated input voltage | 380V |
Rated input capacity | 11.5KVA |
Rated input capacity | 9.0KW |
Rated welding voltage | 22.6V |
Welding current | 4-315A |
Starting current | 4-315A |
Attenuation current | 4-315A |
The current up time | 0.1—20S |
Current decrease time | 0.1—20S |
Note:
1. The above data is only for the customer’s reference.
2. The technical parameters can be customized according to the customer's requestment.
3. We reserve the rights to amend the technical specification here without prior notice.
We specialize in the R&D, manufacturing and marketing of welding sets, Closed Tube Welding Machine, Auto SAW machine for saddle pipe joints, Tube -- tube plate Automatic pulse argon arc welding machine,3D adjustment Long Men posture tube–tube/sheet automatic pulse argon arc welding machine, Orbit tube to tube welding machine.
We also have famous Portable Detector for Quenching Medium Performance. The main markets include many countries in Middle East, Africa, Southeast Asia, and Australia.
Our advantage:
We are always sticking to "clients are our everything". We will do our best to provide favorable price , satisfactory after-sale service. And our welding sets adopt unique design, save energy, convenient for operation, low cost of maintenance and environmentally friendly.
We are the ideal choose for you!
