Low pressure Sauna Steam Generator , 4.5 - 18KW electric steam generators

China China Concrete Autoclave Online Market certification
China China Concrete Autoclave Online Market certification
The company considerate after-sales service ,And try their best to meet the requirement of customers. We will be a long-term cooperation.

—— Albert

Cooperation is very satisfactory and the Company of the past few years, we are very willing to continue long-term cooperation.

—— Dean

I want to say that your products very good. Thank you for all your suggestion, also good after sales service.

—— Mr Abílio Cipriano

I'm Online Chat Now

Low pressure Sauna Steam Generator , 4.5 - 18KW electric steam generators

Low pressure Sauna Steam Generator , 4.5 - 18KW electric steam generators
Low pressure Sauna Steam Generator , 4.5 - 18KW electric steam generators

Large Image :  Low pressure Sauna Steam Generator , 4.5 - 18KW electric steam generators

Product Details:
Place of Origin: China
Brand Name: Alphasauna
Certification: ISO
Model Number: ST series
Payment & Shipping Terms:
Minimum Order Quantity: 1-100pcs
Price: Negotiation
Packaging Details: Packed in carton firstly, and then reinforced with wooden case for outer packing if requested
Delivery Time: 10 working days after received your deposit
Payment Terms: T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability: 300000pcs per month
Detailed Product Description
Product Name: Sauna Steam Generator Size: 445×165×395mm
Power: 4.5-18KW Capacity: 4.8-18KW Acrylic Steam Room
Control Method: Outer Digital Controller Weight: 7-18KGS
Voltage: 220V-240V, 380V-415V Temperature Arrange: 150-110 Centigrade Or 122-230 Fahrenheit
Working Time: Long Time If Prefer To Quantity Of Heater: 3PCS 1.5KW Heating Element
MOQ: Negotiable Water Tank: 304# Stainless Steel
Phase: 1 Phase Or 3 Phase
High Light:

spa steam generator

,

steam bath generators


Sauna Steam Bath Generator Wet Sauna Qualified CE Steam Bath Generator


Fast Information:

1: 4.5-18 KW 220-240V/380v-415V Single phase or 3 Phase.
2: drain by manual.
3: Suggested temperature setting: 45℃.
4: Temperature setting: 35-55℃(95-131℉).
5: Protection of water shortage.
6: Over-high temperature protection.
7: Light system control.
8: time and temperature set up and indication.
9: White color shell.
10: Stainless steel water tank.



Specification

Model Power
(KW)
Voltage
(V)
Current
(A)
Phase
(N~)
Room
(M³)
N*AWG Dimensions
(MM)
Gross weight controller
DO-45 4.5 200-240 18 1 2.5~5 3*10 455*190*380 14KG ST-135M
380-415 7 3 5*14
DO-60 6.0 200-240 27.3 1 6~7 3*8
380-415 9 3 5*13
DO-90 9.0 200-240 41 1 10~12 3*7
380-415 14 3 5*11
DO-105 10.5 380-415 16 3 12~15 5*11 455*190*430 18KG
DO-120 12.0 380-415 18 3 15~18 5*10
DO-150 15.0 380-415 23 3 18~21 5*9

Specification

  Categories   Steam & shower  room
  Application   Wet steam room or shower room
  Material   Matel
  Model   ST-45
  Item   Sauna steam generator
  Size   455*190*430MM
  Max Temperature   55℃
  Packing Volume/ Weight   7-18kgs
  40'GP(PC)   771SETS
  20'GP(PC)   371SETS
  Packing material   Seaworthy Plywood
  Packing size/Canton   53.5*23*59CM
  Controller

  ST-135A controller

  Volume/Canton   0.049CBM
  Delivery time   3-25 days (According your order quantity)
  Term of payment   T/T, L/C, Western Union, Paypal or more
  Shipping method   By Sea/By Air/By Express

Description



Alpha sauna stove has been developed as a direct result of our many years of experience of customer requirement with many new features and improvements. All products has been approved by CE certification.

Remember the pleasure of a steambath at your local health club or during your last vacation getaway? Now think of stepping into your personal steam room in the comfort of your own home!

ST Series steam bath generator is our hottest sales model with best effective-cost advantage. Drain by manual, superior stable working performance, easy installation, easy handle, accurate working mode.

Automatic drain custom request is also avaiable, just need to pay extra payment around 35USD.

White painting color shell, firm body structure design and fully exported qualified standard components.

All machine is guranteed for 1 years of commercial use, 2 years for family use. defective parts can be sent as long as customer prove it is manufacturer's responsibility.

The standard steam generator is the second generation of our products which covers all power sizes from 3KW to 18KW, 220~240V AC or 380~415V AC. When equipped with ST-135M digital control panel, the temperature, working time and even steam room light could be controlled digitally. You could switch between temperature units.

Mineral buildup is the main problem affecting steam generator performance and life of heating elements. Non-resolvable particles in water could be removed by adding filter to the water inlet of steam generator, but resolved scale minerals dissolve under high temperature, and then precipitate layers of rock like deposits inside water tank and on surface of heating elements when water cools down.

As a result of water scale build up, it may clog pipes, affecting heat dissipation of elements and eventually damage them.

Sauna steam bath can be likened to the lazy sports, do not move to move to, we can achieve a passive effect of fitness and beauty, apply to hotels, leisure clubs, beauty massage parlors, bath center, gym, gymnasiums, nursing homes and Hospital, in particular, are well-off white-collar families.



Application


No need for the boiler, fuel, liquefied petroleum gas! Press the steam generator as long as the switch!

Do not need expensive liquefied petroleum gas, gasoline, diesel and other fuels! There is no risk of the most secure machines!



More Feactures



Boiler safety (low pressure), are small because the interior can be used, as well as moving the location of the steam engine can be simple to complete.
Automatically adding water features: electric heating steam generator and steam generated by the proportion of water can be arbitrary; in the course of their work can add water at any time and without shutdown.
Allow the body to maintain normal water level job and uninterrupted provision of external equipment to the high temperature steam.



Explosion-proof safe and efficient design



The new type of electric steam generator due to high temperature of steam instant, real-time job into a state of advanced technology, thus avoiding the reservoir due to steam boost brought about by the bursting of the risk of accidental over-voltage.

Happen in this new type of electric steam browser at the same time has also been adopted in the course of their work need not shut down at random at any time and can increase water's patented technology, thus avoiding accidents due to lack of water heating device dry and the risk of burst damage.

The body using high quality stainless steel. Time-efficient, safe and reliable.
