Specification
|
Model |
WNS1.0-1.0-Y(Q) |
|
|
Rated evaporation capacity |
1.0t/h |
|
|
Rated Steam pressure |
1.0MPa |
|
|
Rated Steam temperature |
184 |
|
|
Feed water temperature |
20 |
|
|
Heating area |
23/11 m2 |
|
|
Thermal efficiency |
92% |
|
|
Fuel available |
Light oil heavy oil nature gas |
|
|
Combustion equipment |
Mechanical & pressure type burner |
|
|
General power |
3.6KW |
|
|
Feed water pump model |
JGGC2-8X16 |
|
|
Consumption
|
Light oil |
66.5kg/h |
|
Nature gas |
77Nm3/h |
|
|
Maximum weight of shipping part |
4T |
|
|
Maximum size of shipping part |
3.6m*2.0m*2.0m |
|
|
Overall size of installation |
4.2m*2.3m*2.1m |
|
