AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station

AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station
AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station

Large Image :  AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station

Product Details:
Place of Origin: Shenzhen, China
Brand Name: ATTEN
Certification: CE/ROHS/SGS/ISO9001
Model Number: AT8586
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: negotiation
Packaging Details: Packed in inner box firstly, and then reinforced with export carton for outer packing
Delivery Time: 3 working days after received the payment
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1,000 pieces per month
Detailed Product Description
Product Name: AT8586 2 In 1 SMD Rework Station Machine Rated Voltage: AC 220V ± 10% 50Hz
Machine Total Power:: 750W (Max) Hot Air Rework Station Operating Voltage: AC 220V ± 10% 50Hz
Hot Air Rework Station Output Power: 700W Welding Table Operating Voltage: AC 26V 50Hz
Welding Table Output Power: 50W Gloss Weight: 3.5kg
High Light:

welding equipments

,

welding tools and equipment

AT8586 2 in 1 SMD rework station , 220V SMD Rework Soldering Station Desoldering Station






Description:
  • Hot air station and soldering station set(the two of them can work separately without mutural interference).
  • Digital LED temperature display, so that the operation more convenient and accurate.
  • Self-examine and error check, with screen remindings to guide people to repair.
  • Adopts Closed-loop control sensors for temperature accuracy and stability.
  • Ideal for safe demolition solder QFP, PLCC, SOP, BGA and other chips and components which are temperature-sensitive.
  • Intelligent cooling system, after the shutdown delay completion of the work of air, air temperature lower than 100 automatically cut off power supply.
  • Use of imported air pump for low vibration, noise-free design and maintain a quiet working environment.
  • Static elimination design, prevent PCB board damage due to static or electric leakage.



Features:


* Machine from the hot air rework station and integrated welding units constitute a multi-functional integrated maintenance system Rework;
* The core of the chip micro-computer chip machine centralized control to ensure the hot air station and soldering station, temperature accuracy and stability rather than a simple combination of two devices;
* Clear digital display the current temperature and working conditions;
* Numerical keys on the temperature of hot air soldering station, temperature and continuous adjustments to adapt to different workplace needs;
* Visual fault indicator.





Specifications:



Machine:
Rated Voltage: AC 220V ± 10% 50Hz
Total Power: 750W (Max)
Work environment :0-40
Relative humidity: "80%
Storage Temperature: -20 -80



Hot air rework station
Operating voltage: AC 220V ± 10% 50Hz
Output Power: 700W
Temperature range: 100 -500
Temperature Stability: ± 5
Gas flow: 120L/min (max)



Welding table
Operating voltage: AC 26V 50Hz
Output Power: 50W
Temperature range: 200 -480
Temperature Stability: ± 2 (static)
Tip to ground resistance: <2Ω
Tip-to-ground voltage: 3mV





AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station 0

AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station 1

AT8586 2 in 1 SMD Industrial Welding Equipment 220V SMD Rework Soldering Desoldering Station 2
