1.Introduction
METO Beer Brewery Equipment is made of high-quality SUS304 stainless steel and can be customized according to customer's requirements and budget withstandard configuration & high configuration.
2. Top Quality Components
1) All product are leading parts in stainless steel 304 and food grate;
2) Complete perfabricated unit, well welded, fine surface, prolong the service life of the equipment;
3) Perfect design, top quality accessories, to minimize the equipment’s bug rate.
3.Full set beer breweryCatalogue
METO Brewery System | Capacity/Volume |
MT-Homebrewery series | 20L,30L,50L,100L pilot/homebrewery system |
MT-Commercial brewery series | 100L--1000L, 3BBL--10BBL pub/restaurant,micro brewery plant |
MT-Microbreweryseries | 200L,300L,500L,1000L |
MT-Pub,Hotel, Bar Brewery | 500L,800L |
MT-Large brewery plant | 1000L--5000L, 10BBL---40BBL brewery plant |
MT-Brewhouse | Two/Three/Four/Five Vessels, Electric/Stream/ Directly Fire heating source |
Fermentation | 100L~10000L conical fermenters,dimple plate jacket |
Bright beer tank | 100L~10000L serving tanks, BBTs, dimple plate jacket |
Beer selling | beer tower, beer selling tank, stainless steel beer kegs, keg filling, keg washing,bottle filling, and etc. |
Standard feature:
*Stainless steel material 304/316
*Exterior thickness: 1.5~3.0mm
*Interior thickness:2.5mm~4.0mm
*Exterior: stainless steel/luxury red cooper
*Flange&dish head(single/double head)
*Temperature sensor
*Top manway
*Polyurethane 80~100mm
*Rotary cleaning ball, 360 degree no dead coner
*Hot water tank available&optional
Pls feel free to contact us if you need any technical help,updated drawing,etc..
4.Technical parameter
Output/Brew | 200L | 300L | 500L | 600L | 800L | 1000L |
Brew/Week | 2~6 | 2~6 | 2~6 | 2~6 | 2~6 | 2~6 |
Output/Week | 400~1200L | 600~1800L | 1000~3000L | 1200~3600L | 1600~4800L | 2000~6000L |
Electric Supply | 3phase/380(220, 415,440…)v/50 (60)Hz Single Phase/ 220(110, 240…)v/50(60)Hz | |||||
Heating Source | Electric/Steam | |||||
Area Request | >25M2 | >30M2 | >45M2 | >50M2 | >60M2 | >70M2 |
Brewmaster | 1 | 1 | 1 | 1 | 1 | 1 |
Tips: 1hl=100liter; 1Gallon=3.7854liter; 1Barrel (BBL) =117Liter;
5.Fermentor Specifications
Function | Beer fermenting for the first stage and the second stage |
Material | 1. Shell - SUS304,316,316L |
2. Jacket - SUS304,316,316L | |
3. Pipes and valves - SUS304,316,316L | |
Configuration | 1. CIP sprayball and CIP pipe |
2. Safty valve | |
3. Sample valve | |
4. Thermometer | |
5. Pressure gauge | |
6. Beer outlet | |
7. Drain | |
8. Butterfly valve | |
9. Manhole |
Tips:100L~60BBL conical fermenters.OEM service available.Can be customized to customer's preference.All pipelines and valves use food grade stainless steel 304 material. Bright beer tanks optional & available.
6.Beer brewing equipment process drawing
7.Options
8.Our Factory
Q1 Can your brewery system make both lager and ale?
A1 Yes. Our brewery system can do this.
Q2 How to do temperature control?
A2 The PLC or digital display meter can control the temperature via connecting with the PT100
sensor.Insulation keep the temperature.
Q3 Is it possible to supply installation in my country?
A3 Yes, our engineers can go to your place and teach your person installation and brewing.
