Product Details:
Payment & Shipping Terms:
|
| High Light: | Flat Vulcanizing Machine,Hydrolic Press Machine |
||
|---|---|---|---|
Quick Detail:
|
Name |
Tire Curing Press |
Brand Name |
ROSNM |
|
Color |
As your request |
Feature |
B (B Center) ,B (hot plate), C (open die vertical lifting) ,4B (4 station after inflating device),Pressure mould locking force,Host structure frame |
|
Warranty |
1 year |
Place of Origin |
CHANGZHOU |
|
control |
PLC |
Certificate |
ISO9001 |
Description:
PRODUCT IDENTIFICATION NUMBER: LLY1650BBC0B
> Max Mould Closing Force:3800KN
> Hydraulic Pressure:17Mpa
> Dia. of Platen:Φ1650mm
> Bead Range:20"-25"
> Power supply: 380VAC±10% 50Hz
> Auxiliary power: 220VAC 50Hz
> Equipment using the environment temperature: Max. 70 ℃
> Circle: ≤70 sec
> Maximum setting steam pressure:(Decided by user)
> Maximum inner pressure nitrogen of vulcanization: 2.4 MPa
> Central organization parameters Capsule type:B TYPE
Stroke of upper ring: 650mm
Stroke of lower ring: 150mm
Diameter of central rod of upper ring: φ48
> Maximum inner pressure of steam: 1.6MPa
> Main body of vulcanizer Types: Frame hydraulic- drive type
> Maximum mold clamping force: 1800KN External-temperature steam pressure 1.2Mpa
Internal-temperature steam pressure 1.6Mpa
Applications:
Used for vulcanization of steel-belted tire
Specifications
|
Model |
RUBBER TIRE |
|
Type of main drive |
Steel-belted tire |
|
Diameter scope of tire |
16″～25″ |
|
Maximum mold clamping force |
4900KN × 2 |
|
Height of vulcanized green tire |
2350～650mm |
|
Mold type |
Segmental mold |
|
Stroke of upper ring |
1150mm |
|
Stroke of lower ring |
150mm |
|
Once-setting nitrogen pressure |
0.02—0.03Mpa |
|
Twice-setting nitrogen pressur |
0.06-0.1Mpa |
|
Nitrogen pressure |
Max. 3.0Mpa |
|
Number of working positions |
4 working positions |
|
Position changing type |
Turn 180° |
|
Adjustment of chuck gap |
Manually/automatically |
|
Three pneumatic components (air pressure regulator, air filter and atomized lubricator) |
SMC |
|
Nitrogen balance valve |
USA HONEYWELL |
|
Displacement pickup |
German Balluff,German ASM,American MTS |
|
Approach switch |
Japan OMRON,Korea AUTONICS,German TURCK |
|
Rotary connector |
Japan ROCKY /Korea VALAS |
|
Hydraulic pump |
Japan YUKEN Germany REXROTH USA VIKERS |
Why to choose our Tire Curing Press
1: Tire pushing device (lower ring)
Each mold is with two oil cylinders and direct pushing type.
2: It’s is structure type, with sufficient rigidity.
3: Main body
The main body consists of rack, opening and closing organization of mold, vulcanization house and adjusting mold organization, pressure organization, central organization and tire pushing device and so on.
4: Tire mounting organization
Consisted by tire holder and single-position tire-storing device, it adopts mechanical claw with double-column structure and oil cylinder for lifting use, whose lifting position can be adjusted, with lifting capacity of the mechanical claw ≥80kg; adopt gas cylinder for turn-in and turn-out, which can be done at the same time on left and right, with buffering device; the claws are short type and its opening and closing operation is driven by air cylinder, with total 6-8 pieces of claws. Air control hose should be placed inside tank chain.
5: Vulcanization house and adjusting mold organization
Regarding labyrinth type of hot plate, the precision of temperature uniformity of hot plate is ±1℃ after increase the temperature.
