Self-Adjustable Pipe Welding Positioner Vessel Loading 8 Ton T-slots For Clamping

Hình ảnh lớn : Self-Adjustable Pipe Welding Positioner Vessel Loading 8 Ton T-slots For Clamping

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	H-WELDING
Chứng nhận:	CE
Model Number:	HB80

Thanh toán:

Minimum Order Quantity:	1 Set
Giá bán:	negotiable
Packaging Details:	Mainframe naked in container, electrical control box in plywood cases (Non fumigation) then in container.
Delivery Time:	15 working days after received your payment
Payment Terms:	30% T/T as advance payment when sign the contract, 70% T/T as balance payment before delivery or 100% irrevocable LC at sight
Supply Ability:	30sets per month

Tiếp xúc

Chi tiết sản phẩm

Product Name:	Self - Adjustable Pipe Welding Positioners	Application:	Pressure vessels
Type:	Self adjustable	T slot No.:	8
Revolve Speed control:	VFD	Tilting speed:	Constant
Work-table shape:	Round or custom	Special design:	Available
Loading:	8000kg	Lifting adjustable:	NO
Làm nổi bật:	weld positioner

Self - Adjustable Pipe Welding Positioners Vessel Loading 8Ton, T-slots For Clamping

Specifications:

Self-Adjustable Pipe Welding Positioner Vessel Loading 8 Ton T-slots For Clamping 0

No.	Item
1	Model	ZHB-03	ZHB-06	ZHB-12	ZHB-30	ZHB-50	ZHB-100
2	Rated load (kg)	300	600	1200	3000	5000	10000
3	Max eccentric distance (mm)	100	150	200	200	200	200
4	Max distance of the gravity center (mm)	150	200	250	300	300	400
5	Worktable φ D (mm)	600	1000	1200	1400	1500	1800
6	Tilting angle(°)	0-90	0-90	0-120	0-120	0-120	0-120
7	Rotating speed (rpm)	0.15-1.5	0.11-1.1	0.11-1.1	0.11-1.1	0.05-0.5	0.03-0.3
	Speed control	VFD for rotation speed
8	Tilting speed (rpm)	manual	1.1	0.4	0.23	0.2	0.14
9	Rotating motor power(kW)	0.18	0.55	0.75	1.5	2.2	3
10	Tilting motor power(kW)	/	0.75	1.5	2.2	3	4
11	Worktable T slot qty	4	4	6	6	6	6

Description:

Worktable is steel welding structure.
Using strengthen tendons to reinforce table and improve table rigidity.
There are several concentric circle slots for positioning. And there are T-slots on the table surface for clamping work piece.

Applications:
