220V Industrial Welding Equipment Hot Air Gun / Soldering Iron SMD Solder Station AOYUE738

220V Industrial Welding Equipment Hot Air Gun / Soldering Iron SMD Solder Station AOYUE738
220V Industrial Welding Equipment Hot Air Gun / Soldering Iron SMD Solder Station AOYUE738

Large Image :  220V Industrial Welding Equipment Hot Air Gun / Soldering Iron SMD Solder Station AOYUE738

Product Details:

Place of Origin: China
Brand Name: Graigar
Certification: CE/ROHS/SGS/ISO9001
Model Number: aoyue738

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: Packed in carrying case firstly, and then reinforced with export carton for outer packing
Delivery Time: 2 working days after received your payment
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pieces per week
Detailed Product Description
Power Consumption:: 550w Temperature:: 100~480C
Output Voltage:: 24v Dimension:: 188(w) X 126(h) X 250(d) Mm
Weight: 6.03KG Automatic Reworking Time:: 20-9999 Seconds
High Light:

welding tools and equipment

,

industrial welding machines

AOYUE 738 SMD Rework Station 220V, Hot Air Gun / Soldering Iron SMD Solder Station AOYUE738 Welding equipment

AOYUE 738 SPECIAL FEATURES:



1. Microprocessor controlled ESD safe unit .All digital display of hot air temperature, soldering iron temperature and air pressure with touch type panel controls.

2. Three in one environment friendly repairing system that combines the function of a Hot Air Gun, a Soldering Iron and a Smoke Absorber.

3. Programmable auto reworking time from 20 to 9999 seconds.

4. Unique 15-minute stand-by auto sleep mode. Returns to previous setting when the handle is held up again.

5. Designed with an auto-cool off process. Upon turning the unit off, it starts to blow cold air until it reaches a safe temperature of 85 degrees, this is to ensure safety and to prolong usage life of the heating element.

6. Creative built-in smoke extractor that absorbs the fumes created at the source. Eliminates the space hindering smoke absorbing units yet allowing a healthy environment

7. Compatible with various type of air nozzles.

8. Compatible with different kind of tips.





AOYUE 738 SPECIFICATIONS



Power Input :

available in 110V / 220V

Station Dimensions:

188(w) x 126(h) x 250(d) mm

Weight:

6.03Kg

SOLDERING IRON

Power Consumption:

45W

Temperature Range:

200 - 480 degrees Celsius

Heating Element with Tip:

Ceramic Heater

Output Voltage:

24V

Tip to Ground Resistance:

Below 2 ohms

Tip to Ground Potential:

Below 2mV

HOT AIR

Power Consumption:

550W

Temperature Range:

100 - 480 degrees Celsius

Heating Element

Metal Heating Core

Nozzle to Ground Resistance:

Below 2 ohms

Pump/Motor Type:

Diaphragm Pump

Air Capacity:

23 l/min (max)

Automatic Reworking Time:

20-9999 seconds

SMOKE ABSORBER

Vacuum Pressure:

600mm Hg





AOYUE 738 Spare Parts list



Part No.

Description

10094

Hot air gun heating element

30105S

Plastic handle of hot air gun

S0738

Hot air gun complete handle

20962

Hot air gun metal pipe

P004

Diaphragm pump

B003

Soldering Iron complete handle

30181X

Filter pods

30150J

Heat resistant pod





AOYUE Package Content:



Main Station with Hot Air Gun

Air Nozzles (1124, 1130, 1197, 1313.1919)

Z003 Hot Air Gun Holder

Soldering Iron with Tip

Soldering Iron Holder with Solder Wire Stand

Filter Pads (2 pcs.)

Vacuum Suction Pen

G001 IC Popper

Power Cord
