Welder Inspection Tools Industrial Welding Equipment Gage Test Ulnar Gauge for Measure Fillet Weld Size

HI-LO WELDING GAGE

MEASURES INTERNAL ALIGNMENT

Of pipe after fit-up/ alignment, cuts radiographic rejects.

Measures internal misalignment of pipe before and after tacking.

Measurements read in standard one side, and metric on the opposite side.

Changes from standard to metric simply remove gauge body,

turn scales over and replace body;

Measure internal misalignment;

Measure fit- up gap

Measure bevel on end preparation;

Measure the crown height of welds;

Measure fillet weld size;

Measure scribed line, socket welds;

Can be calibrated to NBS standard.
