Self Aligning Rotator / Pipe Weld Rotator With PU Roller For Boiler Industry
1. Product feature
● SWR series self-aligning rotators is composed of driven frame and a driving frame.
● Automatically adjusting the center distance in order to adapt to the diameter of work-piece.
● The structure of this machine is made of section steel and steel plate by fine welding, ensuring its structural strength and stability.
● Drive Shaft and Bearing shaft have good rigidity, high strength.
● Wide range of speed regulation, running smoothly.
● Protections against over-current,over-voltage, and over-load, overheating etc.
● Adopting the hand control box can realize the remote operation of the turning roll.
● The hand control box can be used together with the welding manipulator and achieves linkage controlling.
● Convenient operation and high automatic degree to realize high quality welding and automatic welding for the different tanks.
● This product is widely used in wind power, pressure vessel, petrochemical, pipeline, steel structure, boiler, shipbuilding, welding repair industry.
2. Technical parameter
|
Model
|
Loading capacity (kg) |
Pipe diameter (mm) |
Roller diameter & width (mm) |
Roller speed (m/h) |
Motor (kw) |
Speed adjust
|
|
SWR5 |
5000 |
250-2300 |
250*100 |
6-60 |
0.75 |
Variable frequency drive
(VFD)
|
|
SWR10 |
10000 |
320-2800 |
300*120 |
1.1 |
||
|
SWR20 |
20000 |
500-3500 |
350*150 |
1.5 |
||
|
SWR30 |
30000 |
600-3800 |
350*180 |
2.2 |
||
|
SWR40 |
40000 |
600-4200 |
400*160 |
3 |
||
|
SWR50 |
50000 |
700-4500 |
400*200 |
4 |
||
|
SWR60 |
60000 |
750-4800 |
450*180 |
4 |
||
|
SWR80 |
80000 |
850-5000 |
450*240 |
5.5 |
||
|
SWR100 |
100000 |
1000-5500 |
500*240 |
7.5 |
