Product Details:
Payment & Shipping Terms:
|
| Power Consumption:: | 450w | Temperature:: | 100~480C |
|---|---|---|---|
| Power Input: | 110V Or 220v | Dimension:: | 188 X 246 X 127 Mm |
| Weight: | 6KG | AIR CAPACITY：: | 35 L/min (max) |
| High Light: | welding tools and equipment,industrial welding machines |
||
Features:
· ESD safe equipment with grounding measure.
· 2-in-1 system. Combines hot air gun and soldering iron in one package.
· Temperature and airflow adjustable with traditional knob type controls.
· Aoyue 906 series uses high quality Aoyue ceramic heater that is economic and efficient suitable for
most soldering activities.
· Aoyue 908 series uses Japan made PTC heating element that ensures faster heat up suitable for
more demanding soldering requiring 60W of heating power.
· Also available Aoyue 906+ and Aoyue 908+ with built in robotic hot air gun manipulator for stable and
precise hands free reworking.
· Wide selection of solder iron tips for different soldering requirements.
· Compatible with a wide selection of nozzles for various tasks.
|
SPECIFICATIONS |
|
|
POWER INPUT: |
available in 110V / 220V |
|
WEIGHT: |
6 Kg |
|
MAIN STATION DIMENSION: |
188 x 246 x 127 mm |
|
HOT AIR GUN |
|
|
POWER CONSUMPTION: |
450W |
|
TEMPERATURE RANGE: |
100°C- 480°C |
|
HEATING ELEMENT: |
Metal Heating Core |
|
PUMP TYPE: |
Diaphragm pump |
|
AIR CAPACITY: |
35 L/min (max) |
|
SOLDERING IRON |
|
|
POWER CONSUMPTION: |
35W |
|
OUTPUT VOLTAGE: |
24V |
|
TEMPERATURE RANGE: |
200°C- 480°C |
|
HEATING ELEMENT: |
Ceramic heater |
|
TIP TO GROUND RESISTANCE: |
Below 2 Ω |
|
TIP TO GROUND POTENTIAL: |
Below 2mV |
|
AOYUE Int 908+ Package Content |
|
|
1 unit |
Int908+ Main station with hot air gun |
|
1 pc. |
Air nozzles (1124,1130,1196,1197) |
|
1 pc. |
B002 Soldering iron |
|
1 pc. |
2660 Soldering iron holder |
|
1 pc. |
Hot air gun holder |
|
1 pc. |
Vacuum suction pen |
|
1 pc. |
Power cord |
