Product Name: | 10.6 Micron Engraving Lenses | Flatness: | 1/2 λ |
---|---|---|---|
Delivery: | Long Time | Material: | Zinc Selenide |
Operation Wavelength: | 10.6 Micron | Chamfer: | 0.2mm×45° |
High Light: | CO2 F-theta Lens,co2 laser lenses |
10.6 Micron Engraving Cutting For CO2 Laser Welding Equipment
10.6 Micron Engraving Lens
Specification
Wavelength (nm) |
10600 |
Damag Threshold(mW/cm2) |
6 |
Damage Threshold, Pulsed J/cm2 |
8 |
Effective Focal Length EFL (mm) |
103 |
Scan Angle (°) |
0-30 |
Scan Length (mm) |
90 |
Scan Field (mm) |
60*60 |
Entrance Pupil (mm) |
8 |
Spot Size (μm) |
5/6 |
Working Distance (mm) |
125 |
Description:
Laser engraving Lens simplify scanning systems by ensuring a linear relationship between the input scan angle and the focal position on a flat plane. The line includes the 10600nm zinc selenide type F-Theta lens with a short focal length. The short focal length allows users to obtain the smallest possible spot size to improve system resolution. The fused-silica provides better optical transmission than standard N-BK7 glass, particularly for UV and near-UV wavelengths. The increased transmission allows systems to operate with less laser power, extending laser lifetime, and also reduces heat build-up in the lens due to absorption, extending lens lifetime.
The introductions provide a full line of telecentric F-Theta lenses for use in scanning systems such as laser marking and 3D prototyping. Telecentric lenses are designed to eliminate the perspective error found in conventional lens systems, increasing the depth of field for focusing. The combination enhances the ability of scanning systems to handle non-flat surfaces and makes them ideal for cutting or drilling when the process must remain perpendicular to the surface, as in semiconductor and solar panel processing.
Applications:
3D prototyping
Advantage:
Laser Engraving Lens,competitive price , good quality, delivery on time, providing perfect after-sales service, to provide customers with professional customized products of parameter. We will supply you with best solution.
