Rework Station Industrial Welding Equipment AOYUE 909 Soldering Station Repairing System

Rework Station Industrial Welding Equipment AOYUE 909 Soldering Station Repairing System
Rework Station Industrial Welding Equipment AOYUE 909 Soldering Station Repairing System

Large Image :  Rework Station Industrial Welding Equipment AOYUE 909 Soldering Station Repairing System

Product Details:
Place of Origin: China
Brand Name: Graigar
Certification: CE/ROHS/SGS/ISO9001
Model Number: aoyue909
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiation
Packaging Details: Packed in carrying case firstly, and then reinforced with export carton for outer packing
Delivery Time: 2 working days after received your payment
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pieces per week
Detailed Product Description
Power Consumption:: 650W Temperature:: 200°C- 480°C
Power Input: 110V Or 220v OUTPUT VOLTAGE: 24v
Weight: 5.5KG AIR CAPACITY:: 23 L/min (max)
MAIN STATION DIMENSION: Below 2 Ω
High Light:

welding tools and equipment

,

industrial welding machines

AOYUE 909 soldering station repairing system rework station welding equipment



Fatures:

  • ESD safe equipment.
  • 3-in-1 system. Combines hot air gun, soldering iron and voltage supply in one package.
  • Hot air gun temperature control via pulse signal.
  • Cool down mode protects and prolongs hot air gun heating element life.
  • Power supply provides accurate and constant voltage output of 0 -15 . Used as power supply for general trouble shooting and repair.
  • Solder Iron is equipped with high performance ceramic heater with removable tip design.
  • Wide selection of solder iron tips for different soldering requirements.
  • Compatible with a wide variety of hot air nozzles.



SPECIFICATIONS



POWER INPUT:

available in 110V / 220V

WEIGHT:

5.5Kg

MAIN STATION DIMENSION:

204 x 187 x 127 mm

HOT AIR GUN

POWER CONSUMPTION:

600W

TEMPERATURE RANGE:

100°C- 480°C

HEATING ELEMENT:

Metal Heating Core

PUMP TYPE:

Diaphragm pump

AIR CAPACITY:

23 L/min (max)

SOLDERING IRON

POWER CONSUMPTION:

35W

OUTPUT VOLTAGE:

24V

TEMPERATURE RANGE:

200°C- 480°C

HEATING ELEMENT:

Ceramic heater

TIP TO GROUND RESISTANCE:

Below 2 Ω

TIP TO GROUND POTENTIAL:

Below 2mV



AOYUE Int 909 Package Content

1 unit

Int909 Main Station with Hot Air Gun

1 pc.

Air nozzles

1 pc.

B004 Soldering Iron with Tip

1 pc.

2660 Soldering Ion Holder with Solder Wire Stand

1 pc.

Z003 Hot Air Gun Holder

1 pc.

G001 IC Popper

1 pc.

DC Connecting Wires

1 pc.

Power Cord
